Optical CVD Diamond Low Nitrogen, High Transmittance

CVD diamond (also known as Synthetic diamond, Chemical vapor deposition diamond, laboratory-grown diamond, laboratory -created diamond )is diamond produced in an artificial process, as opposed to natural diamonds, which are created by geological processes.

The advantages of CVD diamond growth include the ability to grow diamond over large areas and on various substrates, and the fine control over the chemical impurities and thus properties of the diamond produced. Unlike HPHT, CVD process does not require high pressures, as the growth typically occurs at pressures under 27 kPa
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

We own high performance MWCVD system with dedicated deposition process and suitable seed pretreatment allow offering high-quality single crystal,

Impurities [NV] < 5ppb/ [NV] < 10ppb/ [NV] < 10ppm/ [NV] < 100ppm
Crystallography 100% single sector <100>/<110>
Edge orientation <100>/<110>
Dimensions 2.0x2.0mm or 10.0x10.0mm
Laser cutting Kerf < 5°
Lateral dimensions : +/-30μm
Thickness 300 or 500μm +/-30μm
Roughness Ra < 5 nm on both sides
Thermal conductivity 2000 W/(m.K)

Application
CVD diamond seeds for single crystal growth
Radiation particle detectors
High-power lasers (VCSELs)
Quantum applications
High power electronic devices
High performance tools
Jewelry based on Man-made-diamonds
